Autohil AX2 OBD2 Bluetooth Scan Tool for Android & Windows

Autohil AX2 is a simple and easy to use OBDII Bluetooth car scanner that can help you connect to your vehicle's data using your Android and Windows smart devices. You can diagnose engine trouble codes and know why CHECK ENGINE light is on. You can also customise real-time fuel economy and performance gauges and log engine, trip and fuel data. Autohil AX2 scanner helps you connect to heaps of OBDII Apps available on Google Store giving you more choices on how to use. Simply connect the scanner to OBDII port and pair with your preferred App(s) or Software.

Use Your Smartphone To Get Engine Trouble Codes, Performance Gauges And Live Sensor Data

*picture from TORQUE PRO app

Scanner Benefits

With this simple and easy to use Bluetooth scan tool, you can reliably diagnose engine problems and monitor your car’s real-time performance data using your Android devices.

This scanner will help you:

• Improve your eco-driving with real-time fuel economy data
• Customise a number of OBD-II performance gauges with the type of data you want
• Diagnose your car and discover why your engine light is on and turn it off

Torque Performance App

Torque is a vehicle / car performance / diagnostics tool and scanner that uses an OBD II Bluetooth adapter to connect to your OBD2 engine management / ECU

Customise your own dashboard with the widgets / gauges you want!

Note: App sold separately from Google Play store. Functions and gauges is car dependent and differ from one App to another.

Real-Time Performance Gauges On Your Smartphone

Pair your AX2 Bluetooth Scan Tool to your preferred performance App and see what your car is doing in real-time: get OBD2 fault codes, car performance gauges, live sensor data and more! Real-time performance data include:



Engine RPM	Calculated Load Value	Coolant Temperature
Fuel System Status	Vehicle Speed	Short Term Fuel Trim
Long Term Fuel	Trim Intake Manifold	Pressure Timing Advance
Intake Air Temperature	Air Flow Rate	Absolute Throttle Position
Oxygen sensor voltages	Fuel System status	Fuel Pressure
Fuel Consumption	Trip data	Many others

*OBDII sensor gauges are vehicle dependent.





Diagnose Engine Trouble Codes DTCs

Get engine trouble code & its'meanings right on your smartphone’s screen. Know why your engine light is on and turn it off.

[Reads & Clear DTCs]: Read Engine diagnostic trouble codes DTC and provide both the code and its' meaning and clear them

[Engine Live Data]: Customise and monitor real-time engine parameters.

[Freeze Frame Data]: Recorded system parameters values at the time when engine malfunction first occurred

[Readiness test]: Test and check status of engine emission control systems

[VIN]: Read vehicle info such as Vehicle Identification Number VIN, Calibration IDs CALID and Calibration Verification Number CVN

*Most Apps can only diagnose (read & clear) generic engine fault codes.

---

Easy To Setup Scan Tool

Plug the bluetooth scan tool into your vehicle’s OBD-II port and pair with a performance App of your choice. We recommend TORQUE for Android.

Click here to see the ELM327 Installation Guidelines



Specifications

2018 upgraded 25K80 Chip for faster more reliable readings

Communication : Bluetooth 2.0

Control Chip: PICI8F25K80

Supported Systems: Android / Windows

Operating Voltage: 9-16V

Working current: 35mA

Nominal idle current: 65mAA, and standby current is 45mAH

Power Consumption: 0.75 Watts

Operating Temperature: -15 to 100

Compatible OBDII Protocols

ISO 9141-2 (5 baud init, 10.4 kbaud)

ISO 14230-4 KWP (5 baud init, 10.4 kbaud)

ISO 14230-4 KWP (fast init, 10.4 kbaud)

ISO 15765-4 CAN (11 bit ID, 500 kbaud)

ISO 15765-4 CAN (29 bit ID, 500 kbaud)

ISO 15765-4 CAN (11 bit ID, 250 kbaud)

ISO 15765-4 CAN (29 bit ID, 250 kbaud)

SAE J1850 PWM (Found on many Ford vehicles)

SAE J1850 VPW (Found on many GM vehicles)
