ScanGauge-II OBD2 Trip Computer Digital Gauges & Engine Scan Tool
SGII With Latest Australian Version - Firmware 4.52 AU
ScanGaugeII can help you monitor your vehicle’s most vital systems and provide the kind of real-time information you’ve been missing. Features include more than 15 built-in digital gauges, 5 sets of trip data and an easy-to-use Scan Tool that shows both set and pending trouble codes — all in an ultra compact design that installs in minutes. Scangauge-II displays 4 gauges simultaneously and features X-gauge programmable gauges and the performance monitor.
Digital Gauges
ScanGaugeII provides real-time gauges to show you what is going on “under the hood” with more than 15 built-in digital gauges. The gauge screen allows you to select and display 4 gauges at a time, so you can monitor the current operating conditions of your vehicle in real-time.
- CLSD LP / OPEN LP: Fuel System Loop Status
- MAP: Manifold Absolute Pressure
- BST: Boost
- KPG / LHK / KPL / KPH: Fuel Economy & Consumption
- RPM: Revolutions Per Minute
- TPS: Throttle Position Sensor
- FWT / CWT: Water Temperature
- AVG: Average Fuel Economy
- TFC: Trip Fuel Cost
- CPM: Cost Per Mile
- VLT: Battery Voltage
- FIA / CIA: Intake Air Temperature
- FPR: Fuel Pressure
- GPH / LPH: Litres / Gallons Per Hour
- IGN: Ignition Timing
- LOD: Engine Loading
- HPR: Horsepower
Trip Computers
Five built-in trip computers keep track of everything from fuel cost to distance traveled and everything in between. The TRIP modes in the ScanGauge can be used to save fuel. Improved driving habits can improve fuel economy by up to 30%.
The ScanGauge-II lets you try different driving techniques and routes and gives quick feedback on how they affect fuel use. TANK Trip which you reset when you fill up the tank. It can provide you with “to empty” data as well as other useful information.
- Fuel Economy
- Fuel Used and Cost
- Maximum Coolant Temp
- Distance
- Maximum RPM
- Drive Time
- Maximum Speed
- Average Speed
- Total CO2
- Current Tank of Fuel information : Distance to Empty / Time to Empty / Fuel to Empty
OBDII Engine Scan Tool
ScanGauge-II Can display Diagnostic trouble code, tells you how many there are and the Trouble Codes themselves. Data captured when the Trouble Code was set can be recalled to help troubleshoot the problems.
- Reads Trouble Codes
- Clears Trouble Codes
- Shows Conditions When Trouble Was Detected (RPM, COOLANT, TEMP etc)
- Turns Off “CHECK ENGINE” Lamp
- Shows When Onboard Tests Have Been Completed And Vehicle Is Ready To Pass OBDII emissions Testing
ScanGauge-2 Exclusive Features
X-GAUGE PROGRAMMABLE GAUGES
The ScanGauge-II features the exclusive X-GAUGE™ programmable gauge system. The X-Gauge™ gives you the ability to customise your ScanGauge-II by adding additional vehicle specific digital gauges to monitor parameters such as Transmission Temperature, Trip Data and Fuel Economy information.
PERFORMANCE MONITOR
The Performance Monitor™ allows you to measure and record performance data. You can designate a specific digital gauge to record as well as save and recall the data of up to 8 performance runs for later review and comparison. Performance Monitor lets you step through performance run data by key increments of time, speed and distance giving you a clear picture of your vehicle’s performance.
Specifications
NON-VOLATILE MEMORY(stored information is not lost when disconnected)
- User settings automatically saved
- Up to 10 user commands can be stored and recalled
- Today, Yesterday and Tank Trip data automatically saved
- Vehicle settings automatically saved
EASY INSTALLATION
- No Tools Required!
- Cable detachable at the ScanGauge
- Easily move from vehicle to vehicle
- ScanGauge Compact Size
- Size 4.8"W x 1.4"H x 1"D
AUTOMATIC POWER CONTROL
- Automatic delayed power-down after engine shutoff
- Automatic power-up when engine is started
- Manual power-up with delayed power-down via HOME key
EASY TO OPERATE
- Simple on-screen operation
- 4 menu driven soft keys
- User settable update rate (Slow, Normal and Fast)
- A HOME key to quickly return to the start screen
USER SETTABLE BACKLIGHT
- Display Colour, 7 Standard screen colours and a custom setting with 63 possible colours.
- Backlight for night use
- User settable Off, Low and High
SKU | SGIIAUFFP |
Barcode # | 0788006004122 |
Brand | Scangauge |
Shipping Weight | 0.3500kg |
Shipping Width | 0.120m |
Shipping Height | 0.050m |
Shipping Length | 0.200m |
Unit Of Measure | ea |
