Xtool IOBD2 Mini is the smaller size bluetooth scan tool from Xtool with same great features. Comes with the amazing IOBD2 app at no additional charge or in-App purchases. It will help you monitor your car's engine data on your IOS or Android screens. Includes a number of performance and fuel economy gauges, trip data logger with maps, driving and warning alerts as well as a the ability to read and clear diagnostic engine trouble codes. It works with all OBDII compatible vehicles sold worldwide.

Note: the scanner only reads engine data. It does not cover ABS, SRS, Transmission or other systems outside the fuel and engine system.

Connection type:

  • Bluetooth

Compatible Apps:

  • IOBD2 (IOS & Android)

Customisable Metrics & Alerts

  • Customise units for temperature, mileage, vehicle speed, fuel, fuel consumption, torque and horsepower.
  • Set alarm alerts for over speed, fatigue driving and water temperature
  • Set parameters of vehicle weight, fuel consumption coefficient and vehicle speed coefficient according to your needs.

Four Dashboard Options

  • [Idle mode] Monitor engine rotational speed, water temperature, battery voltage, Air-intake temperature, instant fuel consumption (static), average fuel consumption.
  • [Cruise mode] Monitor vehicle speed, current engine load, water temperature, Vehicle travel time, vehicle travel average speed, Continuous running mileage; instant fuel consumption (dynamic).
  • [Sport mode] Monitor engine rotational speed, vehicle speed, water temperature.
  • [Performance mode] Customise and monitor real-time Engine Parameters including: vehicle speed, capacity, torque & horsepower and more.

OBDII Engine Scan Tool

  • [Reads & Clear DTCs]: Read Engine diagnostic trouble codes DTC and provide both the code and its' meaning and clear them
  • [Engine Live Data]: Customise and monitor real-time engine parameters.
  • [Freeze Frame Data]:Recoded system parameters values at time when engine malfunction first occurred
  • [Readiness test]: Test and check status of engine emission control systems
  • [VIN]: Read vehicle info such as Vehicle Identification Number VIN, Calibration IDs CALID and Calibration Verification Number CVN
  • [Mode 6 & Oxygen Sensor test]: Test and check status of various on-board monitoring systems such as Oxygen Sensors, Catalyst and Evap systems

Performance Tests

  • [0 to 100km/h accelerate/decelerate test] Test acceleration/deceleration process time and distance.
  • [0 to 400m acceleration test] Test spending time from 0 to 400 meters

Car Data Logger

  • Track your driving routes, record DTC's, live data and dashboard data. Know how your car was used, where it went, avg speed and fuel consumption!
  • Share the recorded data using email or social media!

Technical Specification:

  • Dimension: 48*42*25 mm/1.89*1.66*0.99in.
  • Weight: 80g/ 2.83oz.
  • Operating Voltage: 8-19V DC
  • Operating Temperature: -20 to 50°C
  • Storage Temperature: -20 to 70°C
  • Bluetooth Standard: 2.1/2.0/1.2/1.1

Supported OBDII Protocols:

  • ISO15765-4 (CAN)
  • ISO14230-4 (KWP2000)
  • ISO9141-2
  • J1850 VPW
  • J1850 PWM

Package Includes:

  • Hardware: iOBD2 Mini BT adaptor, user manual
  • Software: iOBD2 app-free (Download manually)
SKU XTOOLMINI
Barcode # Does Not Apply
Brand Xtool
Shipping Weight 0.3000kg
Shipping Width 0.120m
Shipping Height 0.050m
Shipping Length 0.200m
Unit Of Measure ea

Crap device doesnt connect to bluetooth

By: on 8 April 2020
Crap device doesn't connect to bluetooth
(1)

www.fueleconomysolutions.com.au Response
Hi Murray, We are sorry to hear that are having troubles to connect. We are unable to locate any aftersales support ticket based on your name/ email address. Please contact our support on support@fueleconomysolutions.com.au so we can troubleshoot.

Product Review IOBD2 Mini

By: on 8 August 2018
The fuel consumption is incorrect - approx. 150% higher than actual otherwise so far it connects readily via bluetooth and is easy to use. Will not know how effective it is until I see an error code.
(3)

IOBD2 Mini OBD II

By: on 1 March 2018
Great little item, once i downloaded the software i was ready to go, selecting the model and year or car was very straight forward, ran the diagnostics and it found the error P2008 and I was able to tell the mechanic the error without being charged for the diagnostics. Great item.
(5)
