SKU: VPK-E4

Vpecker-E4 Bluetooth 8" Tablet Diagnostic Scan ToolSmart System Maintenance Expert System

$1,100.00
In Stock


Calculate Shipping

Description

Vpecker-E4 Diagnostic Smart System

Systems Coverage

ME-Motor electronics, CDI-Common Rail Diesel Injection, ETC-Electronic transmission control, ESM-Electronic selector module, SBC - Sensotronic Brake Control, ESP-Electronic stability program, BAS-Brake assist, Suspension, TPC-Tire pressure monitor, Airbag, CGW-Central gateway, EIS-Electronic ignition switch, OCP-Overhead control panel, UCP-Upper control panel, XALWA-Xenon headlamp, HRA-Headlamp range control, ATA-Anti-theft alarm system, IC-Instrument cluster, ASSYST-Active Service System, SCM-Steering column module, EPS-Electrical power steering, PTS - Parktronic system, EPB-Electric parking brake, COMAND/AUDIO, CD/DVD, TV tuner, CTEL-Cellular telephone, DCM-Door control module, ESA driver-Electric seat adjustment driver, ESA passenger-Electric seat adjustment passenger, AAC-Air conditioning, WSS-Weight sensor system, SVMCM-Special vehicle multifunction control module, etc.



Vehicle Coverage

America:
CHRYSLER, FORD, GM, JEEP, SCION, etc.

Europe:
ABARTH, ALFA, ASTON, AUDI, BENTLEY, BENZ, BMW, BUGATTI, CITROEN, DACIA, FERRARI, FIAT, FORDEU, JAGUAR, LAMBORGHINI, LANCIA, LANDROVER, MASERTI, MINI, OPEL, PEUGEOT, PORSCHE, RENAULT, SAAB, SEAT, SKODA, SMART, VAUXHALL, VOLVO, VW, etc.

Asia:
ACURA, ASIAGM, DAEWOO, DAIHATSU, HONDA, HYUNDAI, INFINITI, ISUZU, KIA, LEXUS, MAZDA, MITSUBISHI, NISSAN, PERODUA, PROTON, SSANGYONG, SUBARU, SUZUKI, TOYOTA, TATA, MAHINDRA, MARUTI,etc.

Australia:
HOLDEN and FORD (AUSTRALIA).

China:
BYD, CHANGAN, CHANGHE, CHERY, EMGRAND, ENGLON, FOTON, GEELY, GLEAGLE, GWM, HBSH, HUACHEN, LIFAN, WULING, YUAN, etc.



Function Coverage

Quick Test, Read ECU Info., Read DTCs, Erase DTCs, Clear learning value, Data Stream, Actuations, Read freeze frame data, Read/Write VIN, Basic Reset, Control unit adaptations, Throttle adaptations, Air bleeding, Level calibration, Theft alarm Reset, Key programming, Oil change, Idle speed learning, Idle speed Adjustment, Ignition timing adjustment, Camshaft timing control learning, Maintenance functions, ECU Initial startup, ECU initialization, etc

Expert Service System (ESS)
Expert service system, according to customers’ requirement list, focus on special functions such as Oil change, Idle speed learning, Idle speed Adjustment, Air bleeding, Level calibration, Throttle adaptations, Steering Angle Sensor Calibration, EPB Reset, DPF Reset, ECU Initial startup, ECU initialization, etc.

Maintenance Service System (MSS)
Maintenance service focus on daily maintenance special functions, such as Oil reset, EPB, TPMS, ABS BLEEDING, DPF, ETS, BATTERY, INJECTOR.



Package includes:

  • Packing box
  • Vpecker E4 VCI
  • Table
  • 12V Charger
  • Quick Start Guide
  • Password Envelope
  • USB Cable
  • Card Reader
  • 16G TF Card



Specifications

Connection Vpecker E4
Operating System Android system above 4.4 version
Dimension 225mm*174mm*24mm
Display 8-inch COF G+G
Memory 1G DDR3
Flash 32G (16G RAM + 16G TF Card)
Camera 500W AF + flash (wide angle)
Battery 4000mAh 4.7V
WIFI+BT WIFI 802.11b/g/n+BT 4.0
Processor ARM 32-bit Cortex processor
Communications Bluetooth
Input Voltage DC 8-16V
Operating Temperature -10 to 70 °C(14-158°F),Relative Humidity:<90%
Storage Temperature -30 to 120°C(-22 to 248°F),Relative Humidity:<90%
Dimension 150mm (5.91”) * 94mm (3.70”) * 40mm(1.57”)
Unit Weight NW:0.07kg (0.154lb) GW:0.166kg (0.366lb)
Protocols UDS,ISO 9141-2, K/L lines, SAE-J1850 ,CAN ISO 11898 ISO 15765-4,High speed,Middle speed ,low speed and Single wire CAN,SAE-J1939,SAE-J1708,SAE-J1587



Connection Professional Diagnostic Tablet
Core Cell CPU RK31881.4
Memory 1G DDR3
Flash 16G
WIFI Support Support 802.11b/g/n
BT Support
Camera Support 500W AF+Flash
Audio Output Support Adopt 8 euro 1W horn
Touch Screen Support COF
Power Supply Adapter 12V/2A



SKU VPK-E4
Brand Vpecker
Shipping Weight 0.2000kg
Shipping Width 0.150m
Shipping Height 0.015m
Shipping Length 0.200m
Shipping Cubic 0.000450m3
